Single Phase Screw Compressor

This compressor runs on standard 220V single-phase power. It is built for small shops, garages, and workplaces where three-phase electricity is not available.

✓ 220V Single Phase✓ 3.7–7.5kW✓ Plug & Play✓ Compact Size

Quick Specifications

Motor Power3.7 / 5.5 / 7.5 KW

Working Pressure8 / 10 / 13 Bar

Air Delivery0.45–1.0 m³/min

Voltage220V / 50Hz or 60Hz

Noise Level62±2 ~ 66±2 dB(A)

Weight150–280 kg

Request Quote Call: +86 155 8905 3798

Factory Direct Price Global Shipping Quality Guaranteed 24/7 Support

Overview

Three-phase power is not always available, especially in small commercial spaces, home workshops, and rural locations. This compressor solves that problem by running on 220V single-phase supply.

Despite the smaller power range (3.7 to 7.5kW), it is a proper rotary screw compressor — not a piston type. It delivers continuous, pulsation-free air suitable for spray painting, sandblasting, and running pneumatic tools.

The unit includes a built-in phase converter and motor protection. Weight starts at 150 kg for the 3.7kW model.

Technical Data

Parameter	Specification
Models	SL-3.7SP / SL-5.5SP / SL-7.5SP
Motor Power	3.7 / 5.5 / 7.5 KW
Working Pressure	8 / 10 / 13 Bar
FAD (at 8 bar)	0.45 / 0.65 / 1.0 m³/min
Voltage	220V, Single Phase, 50/60Hz
Starting Method	Capacitor Start
Cooling	Air Cooled
Noise Level	62±2 ~ 66±2 dB(A)
Outlet Connection	G3/4"
Dimensions (L×W×H)	880×620×820 to 1050×750×1000 mm
Weight	150 / 200 / 280 kg
Certification	CE, ISO9001

Design Highlights

No 3-Phase Needed

Operates from a standard wall outlet. No special electrical installation required.

Quiet Operation

Noise levels start at 62 dB(A) for the 3.7kW model — comparable to a normal conversation.

Small Footprint

The 3.7kW unit measures 880×620×820 mm — about the size of a small desk.

Industry Applications

Auto Repair Shops

Home Workshops

Dental Clinics

Small Manufacturing

Need Help Choosing?

Tell us your air demand, pressure requirement, and application. Our engineers will recommend the right model and provide a quotation.
